How to Read Your Water Meter

There are several reasons why you’d want to be able to locate and read your water meter. First, you might be interested in just how much water you use in a day. By reading your meter at the beginning and the end of the day you can compare the two totals tell how much water you and your family used. The second reason is to check for leaks. If you turn off all the taps in your house, look at your meter and it is still turning, chances are you have a leak somewhere. Here are some hints to help you find and read your water meter.

STEP 1: Locate Your Meter

meterlidYour water meter is generally located near the curb in front of your home. Outside meters are typically housed in a plastic or concrete box usually marked “water” (as shown in the photo) or in a meter pit with a cast iron lid. Carefully remove the lid by using a tool such as a large screwdriver or pliers. Visually examine the area around the meter to make sure there are no harmful insects or other animals.

STEP 2: Read Your Water Meter

Water meters in the U.S. typically measure volume in gallons or cubic feet. One cubic foot = 7.48 gallons and 100 cubic feet = 748 gallons. Water charges are typically based on 1000 gallon units.
There are two basic types of water meters — the straight-reading meter which resembles an odometer in a car, and the round-reading meter which has several separate dials. The “straight-reading” meter is by far the most common.

How to Read a Straight-Reading Meter

straight-readingIn the meter shown in Figure 2, the reading is taken from the figures shown above the words GALLONS. The meter reads 81710.03 which is the total number of gallons of water recorded since the meter was installed. If the utility bills in units of 1000 of gallons, they would read this meter as simply 335.9

The meter shown in Figure 3 is brand new, hence the reading for this meter is 0.00. The small red dial (just to the right of the “35”) is the low flow indicator. That dial will spin if any water is flowing through the meter. This indicator can be useful in leak detection.

How to Read a Round-Reading Meter

round-readingThe meter in Figure 5 is an older style and is much less common, however there are still some of these meters in service. This type of meter has several small dials and is a little more difficult to read than the straight-reading meter. The dials are marked off in divisions of 10, and are read much like a clock, except that the hand on every other dial turns counterclockwise.
To read this meter, begin with the 100,000 dial and read each dial around the meter to the one foot dial. If the hand is between numbers, use the lower number.

Determining the Size of your Water Meter

Occasionally it may be necessary to determine the size of your water meter, for example, if you are designing a new irrigation system. Water meters typically come in the following sizes: 5/8″, 3/4″ (these are the most common residential sizes), 1″, 1.5″, 2″. It is unusual to find anything larger than a 1.5 inch meter on a single-family home. The most common sizes are 5/8″ and 3/4″. The size of the water meter is typically printed on the face of the meter. Sometimes the size is stamped into the case. For Badger Meters, model 25 = 5/8″, model 35 = 3/4″, and model 70 = 1″.
